SPECIFICATIONS

Output Circuit:Isolated output transformer
Regulation:1% line and load
Frequency Response:30Hz to 5KHz for standard model, up to 500KHz for special made models.
Short Circuit Protection:Automatic reset thermostat
Distortion:0.3% mid-band
Input Power:208 50/60 3 phase unless otherwise specified can easily be wired for 190, 225, 240, 380, or 450V; 50/60Hz
Power Factor Range:+0.7 to -0.7 for full power; to zero @ reduced power
Special Output Range:Customer can specify any ranges up to 1500A
Dimensions:19″ rack by 22″ deep 12.25″H for 1000S and 1500S, 17.5″H for 3000S
